1.Opening force refers to mold opening force generated during high-pressure mold open.
2.In the case of opening stroke, data before the slash refer to mold opening stroke with minimum mold height and opening stroke with maximum mold height.
3.Mold-bearing capacity of the movable platen is 2/3 of total mold weight.
4.The shot weight is calculated by GPPS and it is 0.92 times of the theoretical shot volume.
5.The medium screw diameter is standard on the machine.
6.The injection unit data are in international units and calculated as follows: theoretical shot volume [cm3] × injection pressure (MPa)/100
7.The green figures are standard specifications of clamping unit and injection unit.
8.Because of constant technical improvement, the machine specifications are subject to change without notice.
